Integrated Amplifier
The QUAD QII-Integrated evolves the QII into a fully integrated stereo amplifier for the very first time in a user-friendly, yetThe preamp section delivers three line inputs, plus full tape monitoring. Every detail is engineered to the highest standard; even the built-in phono stage is of higher quality than many costly standalone devices, ensuring that every musical source, from vinyl to digital, is delivered with exceptional panache.It stays true to the original QUAD II monoblocks in its push-pull KT66 output configuration and single-tap output transformers, yet it’s actually twice as powerful – rated at 25W per channel.
Valves 4 _ KT66
4 _ 12AX7
2 _ 6922EH
Input Sensitivity 275mV RMS (Line Level & Tape Monitor)
2mV RMS(MM)
200_V RMS(MC)
Output Power 25W per Channel into 8 Ohms
THD 0.06% @ 15W(700Hz)
Hum and Noise Better than -98dBA (ref 25W into 8½)
Frequency Response 20Hz – 20KHz (+0dB/-1dB)
Crosstalk >75dB
Voltage Gain 34dB
Power Consumption 195W (max)
Dimension (H _ W _ D) 200 _ 310 _ 380mm
4 _ 12AX7
2 _ 6922EH
Input Sensitivity 275mV RMS (Line Level & Tape Monitor)
2mV RMS(MM)
200_V RMS(MC)
Output Power 25W per Channel into 8 Ohms
THD 0.06% @ 15W(700Hz)
Hum and Noise Better than -98dBA (ref 25W into 8½)
Frequency Response 20Hz – 20KHz (+0dB/-1dB)
Crosstalk >75dB
Voltage Gain 34dB
Power Consumption 195W (max)
Dimension (H _ W _ D) 200 _ 310 _ 380mm
